Insulating Mortar


Suman Refractory produces a wide range of fireclay and high alumina mortars. These mortars are used as jointing materials for various fireclay and high alumina bricks. Mortars, suitable for different types of insulation bricks, are also manufactured by us. Some of the mortars are supplied as two component system, where liquid binder is separately provided with powder material. In such case, liquid component should be used only as per our recommendation. Where water is used as liquid component, the amount of water used should be such that it results in trowelling consistency.

Brands Insulation Mortar HS Mortar Spl Mortar
Chemical Analysis
Al2O3 % min.204050
Fe2O3 % max.21.51
SiO2 % max.66.85043
CaO % max.0.3--
Physical Properties
Service Temp ºC135015501600
Sintering Temp ºC110011001100
Grain size10.50.5
% Binder for trowelling consistency70 - 7525 - 3033 - 35
Cold Bonding Strength, Kg/cm2-1416
Thermal Properties
P C E, Orton/oC min18 / 152231 / 168332 / 1717
Packaging : 40 Kgs Bags
Storage Life: 12 months
The above data represents typical average properties and do not constitute a specification.
